25MM Miniature Linear Actuator Stepper Motor Permanent Magnet Threaded Shaft

Ask Lasest Price
Brand Name :	JIUQI
Model Number :	25BYZ-22
Certification :	RoHS,ISO9001
Price :	$7~$15/PCS
Payment Terms :	T/T, Western Union,paypal
Supply Ability :	200000 PCS/MONTH
Delivery Time :	Trial orders :2 WEEKS Bulk orders: within 3 weeks

Add to Cart

Product Details
Company Profile

25MM Miniature Linear Actuator Stepper Motor Permanent Magnet Threaded Shaft

25MM Linear Actuator Stepper Motor Threaded Shaft Stepping Motor With High Speed

Applications:Medical equipment,Printer,Scanner,
Gas range,Sewing machine,Auto meter,Robot,and so on.

1. Description:

Linear stepper motor mainly used in valve control, medical equipment, automatic buttons, , printers, robots , textile machines and other related fields.
customizable front plate available
Thrust can be customized
Wiring part can be pin , connecting wires, FPC ,FFC, PCB, etc.

2. Specification

PN	Step angle	Voltage	Phase	Current	Resistance	Inductance	Push force	Start frequency	Rotate frequency	Push distance	Step length
PN	(°)	VDC		mA	Ω	mH	g(200pps)	pps	pps	mm	mm
25BYZ-22	15	12	2	≤250	53	43	≥2	≥500	≥600	22	0.0417
	15	12	2	≤350	30	22	≥2	≥500	≥600	22	0.0417
	15	12	2	≤150	85	65	≥2	≥500	≥600	22	0.0417
	15	5	2	≤300	22	16	≥2	≥500	≥600	22	0.0417
	7.5	12	4	≤250	53	43	≥2	≥500	≥600	22	0.0209
	7.5	12	4	≤350	30	22	≥2	≥500	≥600	22	0.0209
	7.5	12	4	≤150	85	65	≥2	≥500	≥600	22	0.0209
	7.5	5	4	≤300	22	16	≥2	≥500	≥600	22	0.0209

3. Mechanical Dimension:MM

4. Typical Applications

· Medical Equipment
· Automatic Control
· 3D Printer
· Precision Calibration
· Precise Position Movement

5. Terms of trade

Terms of price	FOB,CIF,CFR,EXW,DDP,etc.
Terms of payment	100% T/T in advance for samples
Terms of payment	Bulk quantity payment way can be negotited
Warranty	12 months limited warranty once the items are delivered to the buyer.
Lead time	Usually within 2 weeks for trial orders, within 3 weeks for bulk orders.
Package	Cartons /Pallets
Place of loading	Shanghai, Ningbo, etc.
Delivery time	Usually within 5 working days by Express 15-30 working days by vessel
